THERMASOLV IM6
- Dielectric heat transfer fluid
- Boiling point: 47°C/117°F
- Ultra-low GWP
THERMASOLV IM6
THERMASOLV IM6 is a dielectric heat transfer fluid, dedicated for 2-phase immersion or direct cooling systems. Its high electrical insulation properties allows to immerse electronics & electrical devices under power in the fluid. The favorable characteristics of the product’s viscosity, density and surface tension allows optimal surface contact, which contributes to a superior heat transfer performance. Its very good compatibility with all metals, a wide range of plastics & elastomers and the chemical stability of the fluid, makes THERMASOLV IM6 an ideal fluid for immersion cooling.
THERMASOLV IM6 exhibits also excellent water stability, making it an ideal choice for situations with a high likelihood of water contact or in humid environments.
THERMASOLV IM6 is formulated with safety in mind. It is non-toxic, has no mentioning of any EUH-phrases, is non-flammable and has no flash point.
It is also a great sustainable solution as it has no ODP, ultra-low GWP and can be offered for recycling when needed.
Show links
Hide linksThis is a product
MAIN CONTRIBUTORS WHICH REDUCE IMPACT:
HUMAN HEALTH & SAFETY
- Non-flammable, no flashpoint & no EUH risk phrases: 100% safe for storage and when used in equipment
- Non-toxic & low corrosive impact
ENVIRONMENT PROTECTION & RESOURCES SAVINGS
- No environmental hazard: no H labelling regarding environment
- Can be returned for recycling and re-use: ECOPROGRAM
- Ultra-low GWP
Benefits
Performance
- Excellent thermal conductivity
- Very low surface tension
- Excellent water stablity
- Low kinetic viscosity & low freezing point limit the load on pumps
Cost
- Thermally and chemically stable in use
- Can be returned for recycling and re-use
- No flash point: does not require the use of explosion proof equipment
HSE
- Ultra-low GWP & no ODP
- Non-flammable
- Low environmental impact: GREENWAY product
Process examples
Processes
The product can be used in the following processes:
- Immersion cooling (only 2-phase)
- Direct cooling, where the fluid flows through cold plates or tubes (only 2-phase)
- Specific manufacturing processes which need stable and uniform cooling
- Dielectric testing
Temperature limits
2-phase system
- Boiling Point: 47°C / 117°F
