THERMASOLV CF2
- Dielectric heat transfer fluid
- Boiling point: 110°C/230°F
- Low GWP
THERMASOLV CF2
THERMASOLV CF2 is a dielectric heat transfer fluid, dedicated for 1-phase immersion or direct cooling systems. Its high electrical insulation properties allows to immerse electronics & electrical devices under power in the fluid. The favorable characteristics of the product’s viscosity, density and surface tension allows optimal surface contact, which contributes to a superior heat transfer performance.
Its very good compatibility with all metals, a wide range of plastics & elastomers and the chemical stability of the fluid, makes THERMASOLV CF2 an ideal fluid for immersion cooling.
THERMASOLV CF2 is formulated with safety in mind. It is non-toxic, has no mentioning of any EUH-phrases, is non-flammable and has no flash point.
It is also a great sustainable solution as it has no ODP, low GWP and can be offered for recycling when needed.
Show links
Hide linksThis is a product
MAIN CONTRIBUTORS WHICH REDUCE IMPACT:
HUMAN HEALTH & SAFETY
- Non-flammable, no flashpoint & no EUH risk phrases: 100% safe for storage and when used in equipment
- Non-toxic, no corrosive impact & no S risk phrases
ENVIRONMENT PROTECTION & RESOURCES SAVINGS
- No environmental hazard: no H labelling regarding environment
- Can be returned for recycling and re-use: ECOPROGRAM
- Low viscosity: reduced energy use for pumps
Benefits
Performance
- Excellent thermal conductivity
- Very low surface tension
- High electrical insulation
- Low kinetic viscosity & low freezing point limit the load on pumps
Cost
- Thermally and chemically stable in use
- Can be returned for recycling and re-use
- No flash point: does not require the use of explosion proof equipment
HSE
- Low Global Warming Potential (GWP) & no Ozon depletion potential (ODP)
- Non-flammable
- Low environmental impact: GREENWAY product
Process examples
Processes
The product can be used in the following processes:
- Immersion cooling (only 1-phase)
- Direct cooling, where the fluid flows through cold plates or tubes (only 1-Phase)
- Specific manufacturing processes which need stable and uniform cooling
- Dielectric testing
Temperature limits
1-phase system
- Recommended Temperature Minimum: -95°C / -166°F
- Recommended Temperature Maximal: 100°C / 230°F
2-phase system
- Boiling Point: 90°C / 149°F
