THERMASOLV CF4
Dielectric Cooling Fluids for electronic & electric devices
- Dielectric heat transfer fluid
- Boiling point: 98°C/208°F
- Low temperature viscosity
THERMASOLV CF4
Is a dielectric heat transfer fluid, dedicated for 1-phase immersion or direct cooling systems. It’s high electrical insulation properties allows to immerse electronics & electrical devices under power in the fluid. The boiling point, wide liquid range and low-temperature viscosity of CF4 fluid make it ideal for cooling ion implanters, dry etchers, and CVD machines.
It’s very good compatibility with all metals, a wide range of plastics & elastomers and the chemical stability of the fluid, makes THERMASOLV CF4 an ideal fluid for immersion cooling.
THERMASOLV CF4 is formulated with safety in mind. It is non-toxic, has no mentioning of any EUH-phrases, is non-flammable and has no flash point. It is also a great sustainable solution as it has no ODP and can be offered for recycling when needed.
Show links
Hide linksThis is a product
MAIN CONTRIBUTORS WHICH REDUCE IMPACT:
HUMAN HEALTH & SAFETY
- Non-flammable, no flashpoint & no EUH risk phrases: 100% safe for storage and when used in equipment
- Non-toxic, no corrosive impact & no S risk phrases
ENVIRONMENT PROTECTION & RESOURCES SAVINGS
- No environmental hazard: no H labelling regarding environment
- Can be returned for recycling and re-use: ECOPROGRAM
- Low viscosity: reduced energy use for pumps
Benefits
Performance
- Excellent thermal conductivity
- Very low surface tension
- High electrical insulation
- Low kinetic viscosity & low freezing point, limiting the load on pumps
Cost
- Thermally and chemically stable in use
- Can be returned for recycling and re-use
HSE
- No Ozon depletion potential (ODP)
- Non-flammable & no flashpoint
- Low environmental impact: GREENWAY product
Process information
Processes
The best process will depend on factors such as operating conditions & equipment. Our team is ready to advise you.
Although this product has very good compatibility properties, we cannot foresee all materials that could be exposed to the fluid. We strongly recommend testing before use.
The product can be used in the following processes:
- Immersion cooling (only 1-phase)
- Direct cooling, where the fluid flows through cold plates or tubes (only 1-Phase)
- Specific manufacturing processes which need stable and uniform cooling
- Dielectric testing
Temperature limits
1-phase system
- Recommended minimum temperature: -28°C/-33°F
- Recommended maximum temperature: 85°C/185°F
